Print Colour Management: The One Workflow That Works
The only way to make printed colour match screen appearance is to run a colour-managed chain that uses an ICC profile for every device, soft-proofs under ISO 3664 D50 conditions, and checks the press sheet against a contract proof. Skip any step and the result shifts darker toward magenta. That shift is the claimed-vs-real gap. The screen proof appears to match. The printed sheet does not. The cause is an uncalibrated sRGB workflow that never mapped RGB values to the printer's CMYK space. The fix is a sequence of specific procedures, each governed by a named standard.
Colour Management Workflow: The Chain From Screen To Sheet
Every colour management workflow for print has four stages: capture or creation, display, soft proof, and output. At each stage a device characterisation translates the colour values into a device-independent space. The capture profile assigns a colour space such as Adobe RGB (1998) or sRGB IEC 61966-2-1 to the source image. The display characterisation, created by a hardware colorimeter, describes the monitor's actual behaviour. The output characterisation, a Fogra data set, describes the printing condition. The soft proof simulates the output on the display by combining the source and output descriptions. The final print-ready file embeds an output intent that tells the RIP which printing condition was assumed.
Choose The Working Space Before You Start
Set the working RGB space to Adobe RGB (1998) for images that will be printed. Its D65 white point and gamma 2.2 match most monitors, and its gamut is wider than sRGB, preserving more of the original scene data. Set the working CMYK space to the output characterisation you will use, not a default such as U.S. Web Coated (SWOP) v2. For European coated stock that means FOGRA39 or FOGRA51. For uncoated stock it means FOGRA52. Working in the wrong CMYK space at the start guarantees that the screen colour and the printed colour diverge at the press check.
Fogra ICC Data Sets Coated Uncoated: Which To Use And Why
Fogra characterisation data sets define the expected colour behaviour of a printing condition. They are published by the Fogra Research Institute for Media Technologies and are the basis for ISO 12647-2 process control in offset lithography. FOGRA39, released in 2007, describes coated stock with a total ink coverage limit of 330%. FOGRA51, published later as PSO coated v3, reduces the total ink coverage limit to 300% and adjusts the tone value increase curves to match modern press behaviour. FOGRA52 does the same for uncoated stock, also at a 300% limit. FOGRA53 is a variant for coated stock with lower TVI.
Soft-Proof The Same Image With The Wrong Characterisation
Take a photograph with a saturated red. Soft-proof it with FOGRA39 and then with FOGRA51. The FOGRA39 version shows a red that is slightly more saturated because the higher total ink coverage limit allows more cyan and magenta under the black. The FOGRA51 version appears darker and more subdued. Print both. The FOGRA39 file prints with acceptable density on an older press but exceeds the ink limit on a modern one, causing set-off on the back of the sheet. The FOGRA51 file prints within the press specification. The wrong characterisation produces a print shift that no screen adjustment can fix after the fact.
Embed The Correct Output Intent In The PDF
The PDF must contain an output intent that names the Fogra data set. For PDF/X-4, defined by ISO 15930-7:2010, the output intent is embedded as an ICC profile. The printer's RIP reads this and knows which printing condition the file was prepared for. If the output intent is missing or set to a different characterisation, the RIP applies its own default, which is almost never the one you used. The result is a colour conversion you did not authorise.
Soft Proofing In InDesign: Set Up The Preview Correctly
Adobe InDesign's soft proofing setup simulates printed colour on screen, but only if you configure it correctly. Open the View menu, choose Proof Colors, and then Proof Setup. In the dialog, select Custom. Set the Device to Simulate to the Fogra characterisation for your stock. Set the Rendering Intent to Relative Colorimetric for most images and to Perceptual for photographic images where the gamut is larger than the output space. Enable Simulate Paper Color and Simulate Black Ink. These two checkboxes are the difference between a proof that looks plausible and one that predicts the actual print. Simulate Paper Color shifts the white point of the display to match the paper's D50 value. Simulate Black Ink adjusts the black point to match the printed black density. Without them, the screen shows a contrast range the paper cannot deliver.
What The Wrong Setting Does To The Preview
Disable Simulate Paper Color and leave the rendering intent at Perceptual. The screen shows a bright, high-contrast image. Enable Simulate Paper Color and switch to Relative Colorimetric. The image appears darker, flatter, and slightly yellow compared to the screen white. That darker, flatter image is what prints. The bright version is a lie. Designers who work in the lie are the ones who notice the shift at the press check.
Transparency Blend Space And Overprint Preview
InDesign's transparency blend space defaults to CMYK. Leave it there. Setting it to RGB changes how blended colours are calculated and produces a different result on screen than on press. Enable Overprint Preview from the View menu. Without it, InDesign does not show the effect of overprinting black text on a CMYK background, and you cannot see the registration halo that appears when black knocks out instead of overprints. The black swatch in InDesign overprints by default. Other colours knock out. You must check that the overprint attribute is correct for every black object in the file.
Press Check Colour Evaluation: What To Look For At The Press
A press check is not a design review. You are there to compare the printed sheet to the contract proof under ISO 3664 D50 viewing conditions. The viewing booth must be at 500 lux for appraisal and 2000 lux plus or minus 500 lux for critical comparison, with a D50 illuminant whose chromaticity coordinates are x=0.3457, y=0.3585 and whose correlated colour temperature is 5003 K. Any other light source invalidates the comparison.
Check The Grey Balance First
The G7 grey balance method, defined by IDEAlliance, specifies the CMY values that produce a neutral grey. Look at a grey patch in the midtones. If it has a colour cast, the press needs adjustment before you evaluate any other colour. The FOGRA Media Wedge CMYK v3.0, a 36-patch strip, contains the grey balance patches needed for this check. Measure them with a spectrophotometer and compare the Delta E 2000 values to the ISO 12647-7 proof verification tolerances: average 2.0 or less for primary colours, maximum 5.0, and Delta H 2.5 or less for grey balance.
Compare The Pantone Spot Colour Against The Physical Swatch
If the job uses a Pantone spot colour, bring the Pantone Formula Guide physical swatch to the press check. The screen proof and the printed sheet both approximate the spot colour, but only the physical swatch is the standard. Hold the swatch next to the printed sheet under the D50 booth. If the printed colour falls within the Delta E tolerance, sign off. If it does not, the press operator adjusts the ink density or replaces the ink. Do not approve a spot colour that does not match the swatch. The client will reject the job and you will print again.
Total Ink Coverage And The 300% Limit
Measure the total ink coverage in the darkest area of the image using the Acrobat Output Preview tool. For FOGRA51, FOGRA52, FOGRA53, GRACoL 2013, and SWOP 2013, the limit is 300%. For FOGRA39 the limit is 330%. A value above the limit causes the ink to fail to dry, set off on the back of the sheet, and smear. If the file exceeds the limit, the press operator may reject it. Fix it by reducing the black channel in the dark areas before the press check.
| Data Set | Stock Type | Total Ink Coverage Limit | ISO Reference |
|---|---|---|---|
| FOGRA39 | Coated | 330% | ISO 12647-2:2013 |
| FOGRA51 (PSO coated v3) | Coated | 300% | ISO 12647-2:2013 |
| FOGRA52 (PSO uncoated v3) | Uncoated | 300% | ISO 12647-2:2013 |
| FOGRA53 (PSO coated v3 low TVI) | Coated | 300% | ISO 12647-2:2013 |
| GRACoL 2013 (CRPC6) | Coated #1 | 300% | ISO 15339-2:2015 |
| SWOP 2013 (CRPC5) | Publication coated #3 | 300% | ISO 15339-2:2015 |
Rendering Intent Perceptual Relative Colorimetric: When Each One Fails
The ICC v4 specification defines four rendering intents: Perceptual, Relative Colorimetric, Saturation, and Absolute Colorimetric. For print, you use two of them. Perceptual compresses the entire source gamut into the output gamut, preserving the visual relationship between colours. It is correct for photographic images whose gamut exceeds the CMYK space, which is almost every photograph. Relative Colorimetric maps colours that fall inside the output gamut exactly and clips colours outside to the nearest reproducible value. It is correct for vector graphics, logos, and spot colour simulations where exact hue matters more than the relationship between hues.
Using Perceptual for a logo shifts the brand colours because the compression changes every hue slightly. Using Relative Colorimetric for a photograph clips the saturated blues and greens, turning sky into a flat cyan and grass into a muddy yellow. Adobe applications apply black point compensation by default with Relative Colorimetric. That is not part of the ICC spec but it is standard behaviour. It maps the source black point to the output black point, preventing a washed-out shadow. Leave it on.
Common Questions
Why does my screen proof look correct but the print is darker?
You soft-proofed without Simulate Paper Color and Simulate Black Ink enabled. The screen shows a contrast range the paper cannot deliver. Enable both checkboxes in InDesign's Proof Setup and the preview will show the darker, flatter result that actually prints.
Which Fogra characterisation should I use for coated stock?
Use FOGRA51 for modern offset presses. Its 300% total ink coverage limit matches current press specifications. Use FOGRA39 only if the printer confirms their press is calibrated to the older standard. The wrong characterisation produces a significant print shift.
What is the difference between perceptual and relative colorimetric rendering intent?
Perceptual compresses the entire source gamut into the output gamut, preserving visual relationships. Relative Colorimetric clips out-of-gamut colours to the nearest reproducible value. Use Perceptual for photographs and Relative Colorimetric for vector graphics and spot colours.
How do I check total ink coverage before sending the file?
Open the PDF in Adobe Acrobat Pro and use the Output Preview tool. Set the preview to Separations and look at the Total Area Coverage value. For FOGRA51 it must be 300% or less. A value above the limit causes ink drying failure and set-off.
